RF Filters
CONSTANT IMPEDANCE BPF
Technical Specification
| Part No. |
KG-CIB-3600_4600 |
| N company |
K company |
R company |
S company |
K company |
D company |
| Frequency |
3600 – 3699 MHz |
3701 – 3799 MHz |
3801 – 3899 MHz |
3901 – 3999 MHz |
4001 – 4100 MHz |
4500 – 4600 MHz |
| Bandwidth |
99 MHz |
98 MHz |
98 MHz |
98 MHz |
99 MHz |
100 MHz |
| Insertion Loss |
≤ 2.7 dB |
≤ 3.4 dB |
≤ 2.7 dB |
≤ 3.1 dB |
≤ 3.4 dB |
≤ 0.8 dB |
| VSWR
(All Port)
|
≤ 1.4 dB |
| Isolation |
≥ 30 dB |
| 動作溫度 |
-10℃ ~ 50℃ |
| 保存溫度 |
-20℃ ~ 60℃ |
| Impedance |
50 Ω |
| Protection class |
IP67 |
| Connector Type |
N-Type(Female) |
Key Features
- In band combining and low loss, small size and high attenuation in narrow guard band
- Easy system migration in the same frequency band
- Maximize the usage of guard band and full spectrum utilization
Outline Drawing
